HDMI Bi-Directional Switch

Description

1×2/2×1 HDMI-Compatible Bi-Directional Switch Features

1. Plug and Play
   • No external driver or power is required. The switch activates upon plugging, and a simple button press allows you to shift between input and output sources. An LED indicator displays the active port.
2. Supports 4K Resolution
   • Capable of supporting 4K x 2K at 30Hz, 3D, and 1080P resolutions, as well as HD audio for a high-quality visual and audio experience. (For optimal performance, standard HDMI-Compatible 2.0 cables are recommended.)
3. Fast & Stable Transmission
   • Provides 3.4Gbps data transmission, with support for HDMI-compatible standard cables up to 5 meters for both input and output. This ensures no lag, picture loss, or sound quality degradation.
4. Broad Compatibility
   • Compatible with various HDMI-Compatible devices, including computers, notebooks, Xbox 360, Xbox One, PS3, PS4, Apple TV, Roku, Blu-Ray DVD players, HD-ready/HDTVs, DVB receivers, monitors, and projectors.
5. Bi-Directional Functionality
   • Operates as both a 1-in-2-out or 2-in-1-out HDMI-Compatible switch. Allows connecting two HDMI sources to one display or toggling between two displays for a single HDMI source (only one display can be active at a time).

Specifications

• Power Requirements: Input AC 100-220V (50Hz/60Hz); Output DC 5V (No power adapter included)
• Maximum Current: 1500mA
• Output Line: Supports up to 40m with CAT6 (24/20AWG for output, 26AWG for input)
• Video & Audio Support:
  • Video: 5.0 Volts p-p
  • Transmission Speed: 5.1Gbps
  • Audio Formats: LPCM7.1, Dolby-AC3, DTS, DSD
  • Video Color: 24-bit color
  • Supported Resolutions: 2160P, 1080P24fs, 1080P, 1080i, 720P, 576P, 576i, 480P, 480i
• HDCP Version: HDCP 1.2
• HDMI-Compatible Version: 2.0

This 1×2/2×1 HDMI-Compatible Bi-Directional Switch offers versatility, compatibility, and a high-quality media experience, making it ideal for home and office use.
