USB HDMI Capture Card

Key Features:

1. HDMI-Compatible Audio/Video Capture:
   • Can collect HDMI signals and transmit them to computers and smartphones for preview, recording, and storage.
2. High Resolution Support:
   • Supports input resolution up to 4K for high-quality capture.
   • Outputs at 1080P resolution for smooth playback.
3. Dual Functionality:
   • Features an HDMI loop-out, enabling simultaneous watching and recording.
4. Audio Support:
   • Includes microphone input and 3.5mm stereo output for external audio recording and playback.
5. Color Depth Support:
   • Handles 8/10/12-bit color depth, providing vivid and accurate colors.
6. Long Input Cable:
   • Supports HDMI cables up to 15 meters in length (using AWG26 HDMI cables at 1080P and below resolutions).
7. Compatibility:
   • Works with popular software like VLC, OBS, Amcap, and supports platforms including Windows, Android, and Mac OS.
8. USB Compliance:
   • Complies with USB Video UVC and USB Audio UAC specifications, ensuring broad compatibility without needing additional drivers.
9. Compact Design:
   • No external power supply needed, making it compact and portable for easy carrying and usage on the go.

Specifications:

• HDMI Input Resolution: Up to 4K
• Video Output Resolution: Up to 1080P @ 30Hz
• Video Input Format: 8/10/12-bit color depth
• Video Output Mode: MJPEG
• Audio Format: LPCM
• Input Cable Length: Supports cables up to 15m (AWG26 HDMI standard)
• Power Supply: 0.4A / 5V DC (via USB)
• Operating Temperature: -10°C to 55°C
• Product Dimensions: 68mm x 27mm x 9mm
• Product Weight: 50g

This USB capture card is a versatile and compact tool for video and audio recording in high definition, making it an excellent solution for various professional and personal uses like live streaming, video recording, and more.
